Customization: Available
After-sales Service: Online Support, Video Technical Support
Warranty: 1year
Send Inquiry

Product Description

i

Basic Info.

Model NO. LC-5070PV+UV
Type Vertical Screen Printing Machine
Style Screen-process Printing Press
Structure Rotary Printing Press
Color & Page Multi-Colour Printing Press
Application Packaging Printing
Printing Thickness 0-20 mm
Printing Speed 800PCS/H
Workbench Area 600*800 mm
Max Print Area 500*700 mm
Origin China
📦

Packaging & Delivery

Package Size 177.00cm * 131.00cm * 147.00cm
Package Gross Weight 559.000kg
★

Product Description

Automatic Screen Printing Machine

Automatic Screen Printing Machine For Flat Products with UV Drying machine

This machine is specially designed to greatly improve production efficiency.

  • Manual loading followed by automatic screen printing.
  • Equipped with a mechanical arm for automatic unloading from the screen printer to the UV curing machine.

Advantages:

  • Microprocessor controls for high automation and easy operation.
  • Built-in 4-digit auto counter.
  • Automatic ink scraping, ink withdrawing, and printing scraper lifting.
  • Adjustable printing stroke and speed to meet various requirements.
  • Automatic squeegee balance ensures consistent printing pressure.
  • Fine adjustment capabilities for the worktable and screen frame (horizontal/vertical).
  • High precision printing with easy setup.
  • Equipped with vacuum sorption functionality.

Technical Specifications - Screen Printer

Model Name5070PV
Printing Height50 mm
Air Consumption45 Liter/Min
Working Table Dimension600*800 mm
Max Frame Dimension1050*1150 mm
Max Printing Area500*700 mm
Max Printing Speed800 PCS/h
Squeegee Motor Wattage200 W

Technical Specifications - UV Dryer

Model NOTM-900UVF
Drying Product Size900*100*3000mm
Conveyor Belt SizeL4000* W900mm
UV Lamp Power2PCS * 8KW
Total Wattage26KW
Conveyor Speed0~10m/min
📷

Detailed Photos

Detailed View 1
Detailed View 2
Detailed View 3
Detailed View 4
🎨

Printing Samples

Printing Process

Printing process of multicolor paper bags

Sample Result
🚢

Packing & Delivery

  • Packing: Robust Plywood Case for each machine.
  • Payment Terms: T/T (50% deposit to start production, 50% paid before delivery).
  • Delivery Lead Time: 3-15 business days after payment.
  • Shipping Method: Sea freight delivery.
🏢

Factory Overview

Factory 1
Factory 2
Factory 3
?

Frequently Asked Questions

Q1: Are you a factory or a trading company? A: We are a factory specializing in the manufacture of printing machines and provide comprehensive OEM and after-sales services.
Q2: Can you provide videos showing how the machine operates? A: Absolutely. We have recorded demonstration videos for every machine model to help you understand their operation clearly.
Q3: How is the quality of the machine guaranteed before shipping? A: Every machine undergoes rigorous testing of its working condition before delivery to ensure it meets our high-performance standards.
Q4: Can the machine be customized for specific products? A: Yes. You can send us your product samples, and we will test them on the machine to ensure the design perfectly suits your needs.
Q5: What payment methods do you accept? A: We accept various payment methods, including T/T, PayPal, and L/C.
Q6: Do your machines come with international certification? A: Yes, every model of our machines is CE certified, ensuring compliance with safety and quality standards.
