Full Color High Speed Books Inkjet Digital Printing System

Customization:	Available
After-sales Service:	Online Support
Warranty:	12 Month

Send Inquiry

Product Description

📊 Basic Specifications

Model NO.

VDG108

Plate

Variable Data

Structure

Inkjet Printing

Color & Page

Single-Colour Printing Press

Usage

Paper, Label, Card, Cloths Printer

Automatic Grade

Automatic

Printing Speed

100m/Min

Resolution

150-600dpi

Printing Interface

RS232

System Supported

Windows

Ink Solution

Porous, Semi-Porous and Non-Porous

Origin

China

📦 Packaging & Delivery

Package Size

550.00cm * 150.00cm * 120.00cm

Gross Weight

5000.000kg

🔍 Product Description

This high-speed inkjet digital printer for books and newspapers utilizes industrial piezoelectric on-demand inkjet technology. It significantly improves production speed and spray printing quality. Equipped with high-resolution and high-speed DOD piezoelectric print heads, it meets rigorous demands for mailings, barcodes, bills, checks, and packaging marking.

🚀 Key Features

Industrial Print Heads: Supports Ricoh GEN5, Kyocera 108, or Konica 1024i.
Flexible Integration: Modular design allows easy integration into existing transport systems.
Wide Material Support: Suitable for all kinds of paper, plastics, PVC/PP/PE film, etc.
High Precision: Physics 600 dpi printing precision for crystal clear output.

🛠️ Technical Specifications

Model	VDG540/VDK720/KY108	Print Head	Ricoh GN5/Konica 1024i/KY
Resolution	600×600, 400, 300, 200dpi	Drop Size	5-21PL
Single Head Width	54.0mm / 72.0mm / 108mm	Max Width	Up to 24 Seamless Joints
Printing Speed	Up to 180m/min (600x200dpi)	Inks	Original SGS UV Inks / Water-based
Interface	Gigabit Ethernet	Barcode Types	QR, DATAMATRIX, CODE128, PDF417, etc.

💻 Software Capabilities

The Printer Control Software (PCS) offers a user-friendly interface to monitor status and set options like jetting waveforms and temperature. The Variable Data Printing Software supports text, dates, logos, serial numbers, and database files including .CSV, .XLS, and PDF.

❓ Frequently Asked Questions

What is the lifespan of the printing nozzles?

The industrial piezoelectric nozzles have a normal lifespan of more than 3 years or approximately 10 billion printing times.

What printing speeds can this system achieve?

The speed varies by resolution: 180m/min at 200dpi, 100m/min at 400dpi, and 75m/min at the highest 600dpi precision.

Which materials are compatible with this printer?

This system is versatile and works with various papers, plastics, and films including PVC, PP, and PE.

Does the software support variable data?

Yes, it fully supports variable data printing for barcodes, serial numbers, and database-driven images from Excel or CSV files.

What languages does the control system support?

The software supports multiple languages including English, Spanish, German, French, Portuguese, Russian, and Chinese.

Can multiple print heads be combined?

Yes, the modular design allows for 1 to 24 groups of printing units to be extended with seamless joints.
