Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
1 / 5
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line
Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line

Rotary Screen Gravure Printing Embossing Wallpaper Wallcovering Production Machine Line

Customization: Available
Warranty: One Year
Certification: CE
Send Inquiry

Product Description

Basic Specifications
Model NO.
Customization
Condition
NEW
System Supported
Windowsxp64
Printing Interface
USB2.0
Applicable Material
Paper
Automatic Grade
Automatic
Color & Page
Multi-Colour Printing Press
Capacity
1 Million Rolls Per Year
Electricity
380V, 50Hz, 160kw
Origin
China
Production Overview
●
Final Product: PVC (Vinyl) wallpaper, non-woven wallpaper.
●
Dimensions: Wallpaper width available in 1060mm and 530mm.
●
Speed: Mechanical speed up to 120m/min; Production speed up to 80m/min.
●
Process: 8 colors; embossing, rotary screen & gravure printing.
●
Resource Requirements: Cooling water 50 tons/hour (recycling), Compressed air 0.6~0.8 Mpa, Natural gas approx. 2.5 million Kcal/hour.
Main Equipment List
No. Name Amount
1Unwinding Unit1
2Servo feeding Unit1
3Double servo drive rotary screen printing unit1
4Saving ink type gravure printing unit5
5Chilling for embossing unit1
6Trimming Unit1
7Rewind big roll unit1
8Storage outfeed Unit1
9Rewinding storage Unit1
10Auto rewinding small roll Unit1
Rotary Screen Gravure Printing Embossing Wallpaper Production Line
Frequently Asked Questions
1. What types of wallpaper can this machine produce?
This production line is designed for PVC (Vinyl) wallpaper and non-woven wallpaper.
2. What are the maximum mechanical and production speeds?
The maximum mechanical speed is 120m/min, while the stable production speed reaches up to 80m/min.
3. How many colors can be printed using this machine?
The machine supports an 8-color production process, incorporating both rotary screen and gravure printing.
4. What are the electricity and heating requirements?
The system requires 380V, 50Hz electricity (160kw) and uses natural gas as a heating source (approx. 2.5 million Kcal/hour).
5. What is the annual production capacity?
The production line is capable of producing more than 1 million rolls per year, operating 24 hours a day for 330 days.
6. Does the machine support automatic rewinding?
Yes, the line includes an Auto rewinding small roll Unit and a Rewind big roll unit for efficient handling.
