Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
1 / 5
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications
Jinbao Silk Screen Printing Machine for Efficient Rotary Applications

Jinbao Silk Screen Printing Machine for Efficient Rotary Applications

Customization: Available
Type: Screen Printing
Plate: Screen Printing
Send Inquiry

Product Description

📋 Basic Information
Structure:Flat-Bed Cylinder Press
Color & Page:Single-Colour Printing Press
Model:1020X720mm
Usage:Paper, Label, Cloths Printer
Automatic Grade:Automatic
Printing Speed:3000PCS/H
System Supported:3p 380V 50Hz 14.64kw
Weight:5500kg
Measurement:15.07cbm
HS Code:8443192900
Production Capacity:200sets/Year
⚙️ Product Description

Bottle Screen Printing Machine Silk Screen Printing Machine

The full automatic stop cylinder screen press adopts classical stop cylinder technology. This system offers significant advantages including exact and steady paper location, high precision, high speed operation, and low noise levels. It features a high degree of automation, making it ideally suitable for printing on ceramic and glass appliques, electronic components (film switches, flexible circuitry, meter panels, mobile telephones), packaging, textile transfers, and various special technical applications.

📊 Technical Parameters
Model 720A 800A 1020A
Max. paper dimension 720X520m 800X610m 1020X720m
Min. paper dimension 350X270m 350X270m 560X350m
Max. printing dimension 720X500m 800X600m 1020X710m
Paper thickness 108-400g 108-400g 120-400g
Border ≤ 10mm ≤ 10mm ≤ 10mm
Max. printing speed 1000-3600pcs/h 1000-3300pcs/h 1000-3000pcs/h
Power 3p 380v 50Hz 8.89KW 3p 380v 50Hz 8.89KW 3p 380v 50Hz 14.64KW
Weight (about) 3500kg 4000kg 5000kg
🖼️ Detailed Gallery
Silk Screen Printing Machine Efficiency
Rotary Application Screen Printer
📜 Certifications
Product Certifications
❓ Frequently Asked Questions
1. What materials are compatible with this screen press?
It is versatile and suitable for printing on ceramic appliques, glass, electronic components like film switches and flexible circuitry, mobile phone panels, textiles, and various packaging materials.
2. What is the benefit of the "stop cylinder" technology?
The stop cylinder technology ensures that the paper is located exactly and steadily, resulting in much higher printing precision compared to continuous rotation systems, especially at high speeds.
3. What is the maximum production speed of the 1020A model?
The 1020A model can reach a maximum printing speed of 3000 pieces per hour, while smaller models in the series can reach up to 3600 pieces per hour.
4. Does the machine support automatic operation?
Yes, the series features a high degree of automation, designed as a full automatic stop cylinder screen press to minimize manual intervention and maximize efficiency.
5. What paper thickness can the machine handle?
The machine is designed to handle paper thicknesses ranging from 108g to 400g depending on the specific model selected.
6. What are the power requirements for installation?
The machines typically require a 3-phase 380V 50Hz power supply, with power consumption ranging from 8.89KW to 14.64KW based on the model.
